ID cylinder.

Discussion in 'Chainsaw' started by alleyyooper, Apr 7, 2019.

  1. alleyyooper

    alleyyooper Addicted to ArboristSite

    Joined:
    Oct 21, 2008
    Messages:
    1,670
    Likes Received:
    1,597
    Location:
    Michigan
    A picture of a cylinder for a Husky 55 EPA.

    [​IMG]


    At the base it is marked Marle 44zn15. Does the 44 mean it is 44 MM?

    :D Al

    pioneerguy600 likes this.
  2. alleyyooper

    alleyyooper Addicted to ArboristSite

    Joined:
    Oct 21, 2008
    Messages:
    1,670
    Likes Received:
    1,597
    Location:
    Michigan
    More pictures.
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    :D Al

    cuinrearview likes this.
  3. cus_deluxe

    cus_deluxe Thats what she said.

    Joined:
    Apr 6, 2014
    Messages:
    4,057
    Likes Received:
    4,823
    Location:
    Northern Lower Michigan
    most times it gives you an idea, but not always the same. that one should be 45mm, its the pretty uncommon closed port 55 cylinder. make for really good runners ive heard.

  4. grizz55chev

    grizz55chev Tree Freak

    Joined:
    Dec 9, 2010
    Messages:
    10,727
    Likes Received:
    19,611
    Location:
    northern calif., around auburn
    If you have a piston to go with it.:)

    cus_deluxe likes this.
  5. cus_deluxe

    cus_deluxe Thats what she said.

    Joined:
    Apr 6, 2014
    Messages:
    4,057
    Likes Received:
    4,823
    Location:
    Northern Lower Michigan
    when i built my white top 50 with partner 5000 top end, i used the original 44mm piston and just drilled a hole on either side of wrist pin boss on both sides of piston. id be tempted to do that with a 350 piston or something if i had one of these, rather than go lil red barn.

  6. Huskvarna hotellgäst

    Huskvarna hotellgäst ArboristSite Member

    Joined:
    Feb 14, 2019
    Messages:
    59
    Likes Received:
    44
    Location:
    Australia
    You too?
    I also once dabbled in 50s with P5000+ cylinders. I kept one but it was stolen after only a few hours of use.
    Happily, in those "ancient" times, I had the luxury of new cylinders and pistons, so no drilling required.
    I used a 444 carb, air filter & filter holder, and a blue choke lever off a clearing saw, I think.
    only real problem was that the inertia brake would self activate at about 13,500rpm due to the brake activating spring resonating at the frequency equated with that speed. Solved it by building the old-style pushrod inertia brake mechanism into the new-style cover & handle.

    ncfarmboy, CJ Brown and cus_deluxe like this.
  7. cus_deluxe

    cus_deluxe Thats what she said.

    Joined:
    Apr 6, 2014
    Messages:
    4,057
    Likes Received:
    4,823
    Location:
    Northern Lower Michigan
    no issues with chain break on this one haha. 372 carb and boot

    CJ Brown likes this.
  8. Huskvarna hotellgäst

    Huskvarna hotellgäst ArboristSite Member

    Joined:
    Feb 14, 2019
    Messages:
    59
    Likes Received:
    44
    Location:
    Australia
    Err...no :innocent:

    cus_deluxe likes this.
  9. alexcagle

    alexcagle Cutoff Saw Specialist

    Joined:
    Dec 22, 2010
    Messages:
    5,356
    Likes Received:
    15,569
    Location:
    Broken Arrow,OK
    44mm is the Husqvarna "50", isn't it? 50cc version.

  10. huskihl

    huskihl Addicted to ArboristSite

    Joined:
    Dec 26, 2014
    Messages:
    1,779
    Likes Received:
    2,764
    Location:
    Northern Michigan
    I agree the 55 should have some z's, k's, or n's along with a 45 for a closed port or a 46 for open port.

    A 51 should be a 45mm open port

  11. Huskvarna hotellgäst

    Huskvarna hotellgäst ArboristSite Member

    Joined:
    Feb 14, 2019
    Messages:
    59
    Likes Received:
    44
    Location:
    Australia
    Model 50: 44x32 (49cc)
    Model 51: 45x32 (51cc)
    Model 55: 46x32 (53cc)

    If that Mahle cylinder is 44mm and I'd only seen a picture without the muffler attached, I would have guessed it to be from a Partner 5000+.

  12. alleyyooper

    alleyyooper Addicted to ArboristSite

    Joined:
    Oct 21, 2008
    Messages:
    1,670
    Likes Received:
    1,597
    Location:
    Michigan
    Thanks for the replys, I'm still lost however?!>. is it a 44mm or doesn't the marks mean any thing.
    Would a husky OEM 44mm piston be impossiable to find?


    :D Al

  13. cus_deluxe

    cus_deluxe Thats what she said.

    Joined:
    Apr 6, 2014
    Messages:
    4,057
    Likes Received:
    4,823
    Location:
    Northern Lower Michigan
    you could just measure it and see what diameter it is, and save us all the wondering haha.

  14. cus_deluxe

    cus_deluxe Thats what she said.

    Joined:
    Apr 6, 2014
    Messages:
    4,057
    Likes Received:
    4,823
    Location:
    Northern Lower Michigan
    that could be from a partner, but its not the right muffler and i dont they came with decomps ever. also dont believe the 50 “special” cylinders had decomps either, which is what made me think is was the closed port 55

  15. cus_deluxe

    cus_deluxe Thats what she said.

    Joined:
    Apr 6, 2014
    Messages:
    4,057
    Likes Received:
    4,823
    Location:
    Northern Lower Michigan
    this is for a 281, 52mm,but the base says 54, only to show that the number on the base is not ALWAYS the exact bore.

    alexcagle likes this.
  16. alleyyooper

    alleyyooper Addicted to ArboristSite

    Joined:
    Oct 21, 2008
    Messages:
    1,670
    Likes Received:
    1,597
    Location:
    Michigan
    I was told the cylinder is off a 55EPA sold about 97 or 98.

    Will need to look up a metric to Sae measurement then get back to you.


    :D Al

  17. cus_deluxe

    cus_deluxe Thats what she said.

    Joined:
    Apr 6, 2014
    Messages:
    4,057
    Likes Received:
    4,823
    Location:
    Northern Lower Michigan
    if thats true then its 45mm, closed port 55

  18. Huskvarna hotellgäst

    Huskvarna hotellgäst ArboristSite Member

    Joined:
    Feb 14, 2019
    Messages:
    59
    Likes Received:
    44
    Location:
    Australia
    Ah! Lack of millimetre rule. I was puzzled as to why you just hadn't just measured it.:D

    44mm = 1.732283464566929 inches
    45mm = 1.771653543307087
    46mm = 1.811023622047244

  19. Huskvarna hotellgäst

    Huskvarna hotellgäst ArboristSite Member

    Joined:
    Feb 14, 2019
    Messages:
    59
    Likes Received:
    44
    Location:
    Australia
    Asked as respectively as possible, have you measured the bore? :eek:
    It's just that I have a sneaking suspicion that your 281 cylinder might in fact be a 54mm 288 cylinder.

  20. Huskvarna hotellgäst

    Huskvarna hotellgäst ArboristSite Member

    Joined:
    Feb 14, 2019
    Messages:
    59
    Likes Received:
    44
    Location:
    Australia
    Then open port 55s are 53cc and closed port 55s are 51cc.
    Were the latter a US only version?

    huskihl likes this.
